Home / Product / Household appliance motors / Washing machine motor / BLDC Motor for front loading washing machine

Washing machine motor

BLDC Motor for front loading washing machine

Nanyang has been committed to R&D superior motors with high efficiency, low-noise, low-loss, energy-saving and stable performance.

Nanyang motor - Heart of the world washing machine

This series of motor apply foreign advanced technology, which can meet the replacement of domestic and foreign parts and the use needs of different customers under different working conditions.

Parameter information

It is widely used in various transmission machinery industries of washing machines.

 Model  Application Power Current Voltage Frequency Efficiency Torque Speed Poles Slots Number
NY-BLDC/1 7~10KG 7/10HP 2.6A 0-310VDC 0~1133Hz Wash ≥ 63% 1Nm 565rpm 8 12
Spin ≥ 75% 0.28Nm 16800rpm
12~15KG 3/4HP 2.6A 0-310VDC 0~1133Hz Wash ≥ 75% 1Nm 565rpm 8 12
Spin ≥ 85% 0.32Nm 16800rpm
 Model  Application Power Current Voltage Frequency Efficiency Torque Speed Poles Slots Number
NY-BLDC/2 7~10KG 7/10HP 2.6A 0-310VDC 0~1133Hz Wash ≥ 65% 1Nm 585rpm 8 12
Spin ≥ 75% 0.28Nm 16800rpm
 Model  Application Power Current Voltage Frequency Efficiency Torque Speed Poles Slots Number
NY-BLDC/3 7~10KG 7/10HP 2.6A 220~240V 50/60Hz Wash ≥ 68% 1.2Nm 485rpm 8 12
Spin ≥ 75% 0.37Nm 12800rpm
12~15KG 3/4HP 2.6A 220~240V 50/60Hz Wash ≥ 72% 1.2Nm 485rpm 8 12
Spin ≥ 80% 0.41Nm 12800rpm

Application field

  • Solutions

    Nanyang Motor provides high efficiency, low-noise, low-vibration and systematic solutions.
